SoundQubed S4-100 S Series 4 Channel Amplifier (175x4)
SoundQubed
The S4-100 is a high-efficiency Class D multi-channel amplifier with a host of tone control options. It balances deep and loud low ends with power for mids and highs — 175 Watts per channel in stereo on four channels at 2 Ohm, and 100 Watts per channel in stereo on four channels at 4 Ohm. For more power-hungry systems, it can be bridged to run 375 Watts at 4 Ohm on two channels — ideal for driving one S4-100 per door in competition or sound-quality builds.
The S4-100's high-pass crossover directs precisely tuned tones to tweeters and midrange speakers, preventing damage and interference from low-range bass. The bandpass filter defines what frequencies are eliminated on the high and low end, separating mid-range tone from tweeters, while the included low-pass filter controls how much low frequency reaches your speakers. Power terminals secure cables with 4-gauge set screws; speaker outputs use 10-gauge set screws.
FEATURES
- 4 Channel, Class D
- 175 Watts (RMS) @ 2 Ohm per channel
- 2-Ohm stable
- 4 AWG power/ground inputs
- High-pass, low-pass, and bandpass crossover filters
SPECIFICATIONS
- Class: Class D
- Channels: 4
- Working Voltage: 12-15.8V
- Maximum Amperage: 75A
- Power @ 4 Ohm Stereo: 100W x4 channels
- Power @ 2 Ohm Stereo: 175W x4 channels
- Power @ 4 Ohm Mono (Bridged): 370W x2 channels
- Frequency Response: 10Hz-40kHz
- S/N Ratio: Greater than 80
- Damping Factor: Greater than 100
- Input Sensitivity: 8V-0.2V
- Subsonic Filter: 20Hz-5kHz
- Low-Pass Filter: 50Hz-5kHz
- Dimensions (LxWxH): 7.87 x 7.75 x 2.24 in
SKU: S4-100. Covered by SoundQubed's 12-month warranty against defects in materials and workmanship.
