Cicada 24CXK69 – 2024+ 6x9" Mid-Bass Component Speaker Kit

Cicada 24CXK69 — 6x9" Mid-Bass Component Speaker Kit (2024+)

The 24CXK69 is a big-bore 6x9" component speaker kit for 2024+ Harley builds — a 6x9" Carbon Matrix Composite mid-bass driver paired with a separate 1" shallow ring-radiator horn tweeter with a field-replaceable diaphragm. The larger 6x9 cone moves more air for stronger midbass, while the component layout opens up a wider soundstage than a coaxial. Cicada's Rain or Shine all-weather build keeps everything reliable through rain and heat.

Why we recommend it

The CMC mid-bass is efficient (94dB) and handles 250W RMS for real low-end punch, and the horn tweeter adds bright, clear highs at 101dB. The external 12dB crossover ties them together cleanly, and the field-replaceable tweeter diaphragm makes long-term ownership easy. A great choice when you want more midbass than a 6.5" kit can give.

Fitment & install notes

Built for 2024+ Harley 6x9" component applications. Mid-bass mounting depth 3.26", diameter 5.7" x 8.5"; tweeter mounting depth 1.1", diameter 2.0". Message us to confirm fit for your build.

6x9" Mid-Bass Specifications

• Impedance: 2Ω
• Power Handling: 250W RMS / 500W MAX
• Cone: Carbon Matrix Composite (CMC)
• Voice Coil: 2.0" (51mm)
• Magnet: Neodymium (N35SH)
• Sensitivity: 94dB (1W / 1M)
• Frequency Response: 70Hz – 10kHz (+/- 3dB)
• Mounting Depth: 3.26" (83mm) | Mounting Diameter: 5.7" (145mm) x 8.5" (216mm)

1" Horn Tweeter Specifications

• Impedance: 4Ω
• Power Handling: 50W RMS / 100W MAX
• Tweeter Dome: Aluminum (field-replaceable diaphragm)
• Crossover: 12dB @ 7kHz
• Sensitivity: 101dB (1W / 1M)
• Frequency Response: 2kHz – 20kHz (+/- 3dB)
• Mounting Depth: 1.1" (28mm) | Mounting Diameter: 2.0" (50.8mm)

2-year warranty.
