Ciare CLOC6 – 6-Channel High-to-Low Level Line Output Converter

Ciare CLOC6 – 6-Channel High-to-Low Level Line Output Converter
Ciare CLOC6 – 6-Channel High-to-Low Level Line Output Converter
Ciare CLOC6 – 6-Channel High-to-Low Level Line Output Converter
Ciare CLOC6 – 6-Channel High-to-Low Level Line Output Converter

ciare

$79.99

✔ Manufacturer warranty included ✔ Expert install support available ✔ Fast shipping

Easily upgrade a factory mobile audio system — converts a stereo's speaker output to RCA line-level output for amplifiers and processors. Six-channel version, combining the output and features of the CLOC2 and CLOC4 to add or upgrade a 4.2 (front and rear stereo plus subwoofer) audio system.

FEATURES

  • 6-channel converter for 4.2 (front/rear stereo plus subwoofer) systems
  • Input summing (stereo to mono), ground isolation, and auto turn-on
  • Wide 8-16V operating voltage range
  • Differential balanced inputs for over 100dB signal-to-noise ratio
  • Independent gain controls, selectable ground isolation
  • 40V max input rating; 10V outputs to prevent amplifier clipping

SPECIFICATIONS

  • Operating Voltage: 8-16 VDC
  • Input Voltage: 0-40 VAC
  • Output Voltage: 0-10 VAC

SKU: CLOC6.
